| Construction |
Heavy-duty steel |
| Drive Bay |
External: NB CD-ROM x1 (or equivalent CD-RW / DVD-ROM) + NB FDD x1 Internal: 3.5” HDD x2 |
| Air Filter |
N/A |
| Cooling Fan |
One 12cm ball-bearing fan |
| Indicator |
Power on/off x1, HDD x1 |
| Switch |
Power on/off x1, System reset x1 |
| Speaker |
N/A |
| Connector |
Two USB connectors on the front panel, reserved one COM port cutout |
| Standard Colo |
Black |
| Dimension |
481(W) x 429(D) x 44(H) mm; 19”(W) x 18.7”(D) x 1.7”(H) |
| Weight |
Net: 10 kg (22.05 lb); Gross: 13 kg (28.67 lb) |
| Backplane |
PBP-03P2X: 3-slot (2xPCI) PICMG backplane |
