PQAI-11XE-71

Compact System with Qualcomm^® Dragonwing™ IQ-X SoC for Edge AI Applications

PQAI-11XE-71

PQAI-11XE-71：圖片 2

PQAI-11XE-71：圖片 3

PQAI-11XE-71：圖片 4

PQAI-11XE-71：圖片 5

功能特色

Powered by Qualcomm^® Dragonwing™ IQ-X SoC, delivering up to 45 TOPS of AI performance for edge AI, industrial automation, and AIoT applications
Built on Qualcomm AI Engine, enabling efficient on-device AI inference with low latency and optimized power efficiency for always-on edge computing
Supports 1x M.2 2230 E-Key, 1x M.2 3052 B-Key, 1x M.2 2280 M-Key and UFS
Supporting -40°C to 60°C wide temperature
Support Windows on ARM (WOA) and Linux

Model	PQAI-11XE-71
Sys Form Factor	Proprietary

General
Processor	IQ-X7181, 12-core Qualcomm^® Oryon™ @ 3.4 GHz
Memory	Support up to 32GB LPDDR5 on board
Storage	1 x M.2 Key-M NVMe PCIe x4 2242/2280
	1 x uSD
	1 x UFS(option)

System I/O
Audio	1 x Audio Jack Line-out , Mic-in
Ethernet	2 x 1 GbE LAN
Serial Port	2 x Terminal Block Support RS-232
USB	2 x USB 3.2 Gen2 x1 (10Gbps) Type A
USB	1 x USB 4.0 Type C with DP ALT mode
Display	2 x HDMI^® 2.1
Display	1 x DP 2.1 colay with USB3.2 Gen2x1 Type-C
Other	Power Button, Reset Button
LED	Power, Storage, Programmable LED
Antenna	6 x SMA Antenna holes for LTE / 5G / Wi-Fi
SIM Slots	1 x Nano-SIM

Expansion I/O
M.2	1 x B Key w/ 3052
M.2	1 x E Key w/ 2230

ME/Environment
Dimension (WxDxH)	152 x 112 x 92 mm (5.98″ x 4.41″ x 3.62″ )
Weight	1.7 kg
Power Supply	Terminal Block 12V
Mounting	Wall Mount, DIN Rail Mount, VESA Mount (75*75)
Vibration	1G 5~500Hz with Wall mount (IEC/EN 60068-2-6)
Vibration	0.5G 5~500Hz with Din rail (IEC/EN 60068-2-6)
Shock	30G 11m sec with Wall mount (IEC/EN 60068-2-27)
Operating Temperature	-40 ~ 60 °C (-40.0 ~ 140.0 °F)
Storage Temperature	-40 ~ 85 °C (-40.0 ~ 185.0 °F)
Cooling	System 1 x Fan
Relative Humidity	5% to 95%, non-condensing
Certification	CE/FCC/UKCA Class B
OS	Windows on ARM, Linux™
Portwell Special Feature	PET
